Product Overview
H1APC Hurricane Tie (Carton of 25pcs)
ORNAMENTAL HURRICANE TIE PC/ZMAX
The Outdoor Accents H1APC connects a truss or rafter to walls or beams. The H1APC is designed for nominal 2x lumber. With its U-shaped design, it installs faster than a pair of single-sided ties. Embossments add stiffness in crucial areas for improved performance. The H1APC installs with premium, color-matched Outdoor Accents connector screws. This hurricane tie is made from ZMAX galvanized steel for superior corrosion resistance with a stylish black powder-coat for added beauty.
Key Features
- Connects a nominal 2x truss or rafter to a wall or beam
- Helps resist wind and seismic forces
- Can be installed on the inside or the outside of a wall, or on both sides
- Provides faster installation than using two single-sided ties
- Can be installed with flanges facing either inward or outward
Material
- 18 gauge
Finish
- ZMAX galvanized steel with black powder coat
Installation
- Use all specified fasteners; see General Notes.
- Hurricane ties do not replace solid blocking.
- When installing ties on plated trusses (on the side opposite the truss plate), do not fasten through the truss plate from behind. This can force the truss plate off the truss and compromise truss performance.
